• Remarkable efficient performance in 80lm/w at least, reducing electricity costs and energy efficiency.
• 6063 / 6061 aviation aluminum alloy frame, no rust and anti corrosion.
• High-quality light guide plate(LGP) PMMA(polymethyl methacrylate), offering a stable and homogeneous light distribution 112° beam angle.
• Applied to Office, Conference, Classroom, Library etc.
• Frame：6063 /6061 aviation aluminum alloy
• Finishing Color: White, Black, Silver and other colors on request(Depending on quantity)
• Light Guide Plate(LGP): PMMA acrylic
• Diffuser: Anti-yellow Polystyrene (PS) or Polycarbonate (PC) diffuser
• Installation Way: Recessed, Surface Mounted, Suspended
• Warranty: 5 Years
• Ingress Protection: IP20
• Flicker: Free • Option: Mounting Frame, Suspension Wire, Clips, Rope
LED Chip:
Color Temperature(CCT): 2700K/3000K/4000K/5000K/6500K
RA>80， SDCM6/5/3
Beam Angle: 112°
Driver:
AC220-240V / 100-277V, 50/60Hz
PF>0.90
Flicker Free
ON/OFF/ 0-10V / DALI dim.
Working lifespan:50,000hours
| Model | Watt.(W) | Dimen.(mm) | Efficiency(lm/w) |
| LC-PELEDXX | 12-24 | 295*295*10 | 80-110 |
| LC-PELEDXX | 18-24 | 295*595*10 | 80-130 |
| LC-PELEDXX | 24-60 | 295*1195*10 | 80-150 |
| LC-PELEDXX | 24-60 | 595*595*10 | 80-160 |
| LC-PELEDXX | 50-60 | 595*1195*10 | 80-160 |
